Victron Energy SmartSolar MPPT 250/100-Tr Solar Charge Controller

A SmartSolar MPPT charge controller efficiently captures energy from your solar panels and uses it to charge and maintain your battery bank. Using advanced charging technology, SmartSolar maximizes available solar energy to help batteries reach a full charge quickly and efficiently while supporting long-term battery health.

Advanced Maximum Power Point Tracking (MPPT) technology continuously monitors the voltage and current produced by your solar panels and automatically adjusts to maximize energy harvest. This is especially beneficial during changing conditions, such as partial cloud cover or fluctuating sunlight.

With built-in Bluetooth, SmartSolar can connect wirelessly to a smartphone or compatible device using the VictronConnect app. From the app, you can monitor system performance, adjust settings, and access important charging information. For internet-connected systems, the Victron Remote Management (VRM) Portal provides additional remote monitoring capabilities from virtually anywhere.

For convenient on-site monitoring, the optional SmartSolar Control Display connects directly to the front of the charge controller, providing an easy way to view charger and battery status, monitor performance, and adjust settings in real time.

Note: Charger Controller doesn't come with optional pluggable display.

Features and Specifications:

• Ultra-fast Maximum Power Point Tracking (MPPT)
• Advanced Maximum Power Point Detection in case of partial shading conditions
• Outstanding conversion efficiency
• Flexible charge algorithm
• Internal temperature sensor
• Bluetooth Smart built-in: dongle not needed
• Programmable relay
• Optional: pluggable LCD display
• Battery voltage: 12, 24, 48 Volts DC (36VDC can be set up with software tool)
• Rated charge current: 100 Amps
• Max. PV short circuit current: 70 Amps
• Maximum wire size: #2 AWG
• Weight: 9.92 lbs (4.5 kg)
• Dimensions (inches / millimeters): 8.5" x 11.61" x 4.06" / 216 x 295 x 103 mm
• 5 year warranty with Victron
